Dimensions
Width: 30" (76.2 cm)Height: 4.56" (11.6 cm)Depth: 19.56" (49.7 cm)
Shipping Dimensions
Width: 33" (83.8 cm)Height: 7.56" (19.2 cm)Depth: 22.56" (57.3 cm)
Weight
44.50 lbs (20.2 kg))
Key Features:
- Quick Boil
- Low-Simmer Burner
- Continuous Grates
- Express-Select Controls
Quick Boil
Speed up the cooking process with this cooktop’s quick boil feature, which rapidly takes liquid from a simmer to a boil.
Low-Simmer Burner
Use this burner to perfectly simmer delicate foods and sauces, such as poached eggs or raspberry coulis.
Continuous Grates
Seamlessly move heavy pots and pans between burners without lifting.
Express-Select Controls
Experience precise temperature control at your fingertips and cook like a pro.
Detailed Specifications
General:
- Power Type: Gas
- Size: 30"
- Approved for Electric Single-Wall Oven Combination Installation
- Gas Supply Connection Location: Right Rear
- Control Location: Front
- Amps @ 120V: 1.0
- Minimum Circuit Required (Amps): 15
Cooktop Features:
- Cooking Surface: Recessed
- Grate Type: Continuous Cast Iron
- Grate Colour: Black Matte
- Knob Type: Cast Metal
- Burner Type: Sealed Gas
- Left Front: 12,000 BTU
- Left Rear: 9,500 BTU
- Right Front: 18,000 BTU
- Right Rear: 5,000 BTU
